MULTI OUTDOOR 22 SEER
Multi Zone
DESCRIPTION
Reliable, efficient, sophisticated and powerful are the words that best describe the Multi 22 series. The Multi 22 series is a very quiet, wifi capable, inverter driven mini-split using R410A refrigerant that is engineered to provide heat even at -5° F. The subtle indoor unit panel will blend in any type of room, also you can use Cassette, slim-duct, console or Floor-ceiling units to cool or heat your environment.
16/22 HSPR/SEER 18K/56K BTU CAPACITY
| MODEL | BBM18H40 | BBM24H40 | BBM30H40 | BBM36H40 | BBM42H30 | BBM48H20 | BBM56H20 | ||
| Number of ports | 2 ports | 3 ports | 4 ports | 5 ports | 5 ports | Up to 8 units | Up to 8 units | ||
| Capacity | Cooling | Btu/h | 18,000(6,998-21,000) | 24,000(7,500-33,000) | 28,400(8,188-33,438) | 34,000(8,871-35,826) | 39,000(8,871-40,944) | 47,800(3,412-54,592) | 53,000(3,410-61,420) |
| Heating | Btu/h | 19,000(7,000-22,600) | 26,000(7,500-27,978) | 30,600(8,189-32,414) | 42.500(8,871-44,356) | 45,000(8,871-46,062) | 54,600(4,090-59,368) | 61,500(4,090-63,120) | |
| SEER | 22 | 21 | 21 | 21 | 21 | 16 | 16 | ||
| HSPF / COP | 10.5/3.66 | 10.5/3.72 | 10.5/3.74 | 10.5/3.70 | 10.2/3.61 | 8.20 | 8.20 | ||
| Power Supply | 208-230V,60Hz, 1Ph | 208-230V,60Hz, 1Ph | 208-230V,60Hz, 1Ph | 208-230V,60Hz, 1Ph | 208-230V,60Hz, 1Ph | 208-230V,60Hz, 1Ph | 208-230V,60Hz, 1Ph | ||
| Airflow | CFM | 1,883 | 2,354 | 2,354 | 4,531 | 4,531 | 3,766.40 | 4,119.5 | |
| Operating Range | Cooling | °C | -18 ~ 48 | -18 ~ 48 | -18 ~ 48 | -18 ~ 48 | -18 ~ 48 | -5 ~ 43 | -5 ~ 3 |
| °F | 0 ~ 118 | 0 ~ 118 | 0 ~ 118 | 0 ~ 118 | 0 ~ 118 | 23 ~ 109 | 23 ~ 109 | ||
| Heating | °C | -20 ~ 24 | -20 ~ 24 | -20 ~ 30 | -20 ~ 30 | -20 ~ 30 | -20 ~ 20 | -20 ~ 20 | |
| °F | -5 ~ 75 | -5 ~ 75 | -5 ~ 86 | -5 ~ 86 | -5 ~ 86 | -5 ~ 68 | -5 ~ 68 | ||
| Sound Pressure Level | dB(A) | 56 | 58 | 59 | 61 | 61 | 65 | 67 | |
| Piping Connection | Gas | inch | 2 x 3/8 | 3 x 3/8 | 4 x 3/8 | 5 x 3/8 | 5 x 3/8 | 3/8 | 3/8 |
| Liquid | inch | 2 x 1/4 | 3 x 1/4 | 4 x 1/4 | 5 x 1/4 | 5 x 1/4 | 5/8 | 5/8 | |
| Dimensions WxHxD | inch | 37.6 x 27.55 x 15.6 | 38.6 x 31.1 x 16.8 | 38.6 x 31.1 x 16.8 | 42.8 x 43.4 x 17.3 | 42.8 x 43.4 x 17.3 | 53.14 × 35.44 x 13.39 | 53 × 35.44 x 13.39 | |
| Net/Gross Weight | Lbs | 114.25/125 | 152.9/164.2 | 154/169 | 198/216 | 198.4/216 | 255.74/282 | 255.74/282 | |
| Max. Total Distance | ft. | 65.6 | 196.8 | 229.6 | 246 | 246 | 443 | 476 | |
| Max. Single Distance | ft. | 49 | 65.6 | 82 | 82 | 82 | 180 | 180 | |
| Max Elevation | ft. | 49 | 49 | 49.2 | 49.2 | 49.2 | 98 | 98 | |
| Refrigerant Charge | ft. | 3.5 | 4.8 | 6.2 | 8 | 8 | 25 | 25 | |
| MOCP | A | 25 | 30 | 30 | 35 | 40 | 30 | 30 | |
